Semi Agv Automated Parking System for Cars

Basic Info

Model No.: PPY

Brand: Fengye

Place Of Origin: China

Dimensions Of Cars: 5300mmx1950mmx2050mm

Drive Mode: Motor-driven

Power Supply: 3 phase 5 line

Surface Treatment: Hot dip galvanizing

Operating Mode: Swipe card or Touch screen

Control Method: PLC

Load Capacity: 2000kg-2500kg

Additional Info

Productivity: 50000 parking spaces/year

Transportation: Ocean,Land

Place of Origin: Jiangsu,China

Supply Ability: 50000 parking spaces/year

Certificate: ISO9001/GBT33000

HS Code: 84289020

Port: Shangha,Tianjin,Lianyungang

Product Description

Performance characteristics of the semi agv Automated Parking System

1. Fully automated Mechanical Parking Equipment, robot handling method, fast storage (retrieval) speed;

2. No need for ramps, saving land occupation, high vehicle density, and maximizing land use efficiency;

3. It is most suitable to be built in large garages with relatively short tunnel lengths but multiple floors;

4. Equipped with safety protection devices, it is safe and reliable to use, avoiding various unexpected incidents;

5. Optoelectronic safety detection, controlling vehicle specifications and parking quantity;

6. Generally, there is no need for forced ventilation, no large-scale lighting, and energy savings.

Matters Needing Attention during Use

1. Learn to use the "Emergency Stop Button"

Generally, there is a red button on the control panel of the mechanical parking garage, which is the "Emergency Stop" button. When the equipment is running abnormally, press this button immediately. This can make the equipment stop running instantly to prevent the occurrence of accidents!

2.Pay Attention to parking dimensions

At a conspicuous location in every parking lot, there is a sign indicating parking dimensions. On the sign, the dimensions of vehicles that can be parked in the mechanical bays are marked. In fact, mechanical parking bays currently available on the market can generally accommodate vehicles within 5 meters in length. However, for some oversized vehicles, they definitely cannot be parked. Therefore, during use, be sure to choose a stereoscopic parking bay suitable for your vehicle!
